DC SHUNT MOTOR — MOE Lab Tender Details

DC SHUNT MOTOR COUPLED WITH AC SYNCHRONOUS ALTERNATOR.

SCOPE OF LEARNING:

• Study of DC Shunt Motor to AC Alternator

TECHNICAL SPECIFICATIONS:

Power Supplies:

• DC Power Supply +230V AT 2A (Internal)
• Operated on Mains power 415V, 50Hz +10%

Digital/Analog Meters:

• Voltmeter
• Ammeter

Components mounted on the panel:

• Variac 4A (2Phase)
• DC Starter (3 Point)
• Lamp Load (Switched Control)
• Emergency Stop Switch.

FEATURES:

• Front panel built with high class insulated Bakelite sheet with Sticker well printed circuits and symbols.
• The trainer is housed in Modular Based Rack Type Aluminum Extruded Metal cabinet.
• Instruction manual.
• Patch Cords 4mm (Heavy Duty)
• High Voltage Test Points are Provided With 4mm Safety Sockets
• The trainer is housed in Metal cabinet.
• Protection with Emergency Stop.
• Short Circuit protection with the MCB.
• Size of the trainer set 30”x24”

MOTOR SPECIFICATIONS:

• DC  Motor 2HP, 230V and AC Alternator 415V (1KW).
